EcoScreen Sapphire Coarse Dirt Filter
EcoScreen Sapphire (Saphir) is a coarse-debris filter for stormwater pre-treatment. High-performance screening retains leaves, debris and solids ≥ 5 mm (ASTM E3332-23 tested).
Brand
GRAF
Range
Stormwater
SKU
340115
Selected SKU
340115
Price on request
Upload plans on the quote form for civil sizing, pump station design, or treatment plant PE calculations.
Typical applications
Technical sizing
Size matrix & SKUs
1 technical row - select above or quote directly
Load class
| Size | Length | Width | Height | Weight | Load class | Order no. | Quote |
|---|---|---|---|---|---|---|---|
| Standard | 1,270 mm | 1,155 mm | 1,685 mm | 95 kg | - | 340115 |
- Retains solids ≥ 5 mm · ASTM E3332-23 tested
Technical data source: https://www.graf.info/en/products/rainwater-treatment/ecoscreen-sapphire-coarse-dirt-filter.html
Full specification
Product details
Key construction, installation and performance notes for EcoScreen Sapphire Coarse Dirt Filter.
Overview
EcoScreen Sapphire (Saphir) is a coarse-debris filter for stormwater pre-treatment. High-performance screening retains leaves, debris and solids ≥ 5 mm (ASTM E3332-23 tested), reducing load on downstream treatment. Tangential inlet creates hydrodynamic flow for settling; flow-separated chamber with breakers; integrated bypass with filter screen; filter area >15× inlet cross-section. Source: graf.info EcoScreen Saphir.
Specification focus
