Carat Septic Tank — One / Two Chamber

Baffled Carat septic — one or two chamber

Brand

GRAF

Range

Wastewater

Sizes

Lid types

Size

Lid / load class

Selected SKU

10.0001

Price on request

Talk to us

Upload plans on the quote form for civil sizing, pump station design, or treatment plant PE calculations.

← Back to Wastewater

Certified qualityISO 9001 · AS/NZS standards

5-year warrantyOn wastewater treatment products

Recycled plasticsSustainable manufacturing

Typical applications

Off-grid sites

Commercial

Remote / rural

Technical sizing

Size matrix & SKUs

24 technical rows - select above or quote directly

Load class

Pedestrian coverClass B vehicle coverClass D truck lidGrated pedestrianGrated Class BGrated Class D

KeyPedestrianClass BClass DClass BGrated

Size	Length	Width	Height	Weight	Lid / variant	Load class	Order no.
2,700 L	2,080 mm	1,565 mm	2,010 mm	120 kg	Pedestrian cover	Pedestrian	372024
2,700 L	2,080 mm	1,565 mm	2,010 mm	120 kg	Class B vehicle cover	Class B	372024
2,700 L	2,080 mm	1,565 mm	2,010 mm	120 kg	Class D truck lid	Class D	372024
2,700 L	2,080 mm	1,565 mm	2,010 mm	120 kg	Grated pedestrian	PedestrianGrated	372024
2,700 L	2,080 mm	1,565 mm	2,010 mm	120 kg	Grated Class B	Class BGrated	372024
2,700 L	2,080 mm	1,565 mm	2,010 mm	120 kg	Grated Class D	Class DGrated	372024
3,750 L	2,280 mm	1,755 mm	2,200 mm	150 kg	Pedestrian cover	Pedestrian	372025
3,750 L	2,280 mm	1,755 mm	2,200 mm	150 kg	Class B vehicle cover	Class B	372025
3,750 L	2,280 mm	1,755 mm	2,200 mm	150 kg	Class D truck lid	Class D	372025
3,750 L	2,280 mm	1,755 mm	2,200 mm	150 kg	Grated pedestrian	PedestrianGrated	372025
3,750 L	2,280 mm	1,755 mm	2,200 mm	150 kg	Grated Class B	Class BGrated	372025
3,750 L	2,280 mm	1,755 mm	2,200 mm	150 kg	Grated Class D	Class DGrated	372025
4,800 L	2,280 mm	1,985 mm	2,430 mm	185 kg	Pedestrian cover	Pedestrian	372026
4,800 L	2,280 mm	1,985 mm	2,430 mm	185 kg	Class B vehicle cover	Class B	372026
4,800 L	2,280 mm	1,985 mm	2,430 mm	185 kg	Class D truck lid	Class D	372026
4,800 L	2,280 mm	1,985 mm	2,430 mm	185 kg	Grated pedestrian	PedestrianGrated	372026
4,800 L	2,280 mm	1,985 mm	2,430 mm	185 kg	Grated Class B	Class BGrated	372026
4,800 L	2,280 mm	1,985 mm	2,430 mm	185 kg	Grated Class D	Class DGrated	372026
6,500 L	2,390 mm	2,190 mm	2,710 mm	220 kg	Pedestrian cover	Pedestrian	372027
6,500 L	2,390 mm	2,190 mm	2,710 mm	220 kg	Class B vehicle cover	Class B	372027
6,500 L	2,390 mm	2,190 mm	2,710 mm	220 kg	Class D truck lid	Class D	372027
6,500 L	2,390 mm	2,190 mm	2,710 mm	220 kg	Grated pedestrian	PedestrianGrated	372027
6,500 L	2,390 mm	2,190 mm	2,710 mm	220 kg	Grated Class B	Class BGrated	372027
6,500 L	2,390 mm	2,190 mm	2,710 mm	220 kg	Grated Class D	Class DGrated	372027

Technical data source: GRAF Carat S manufacturer sizing table

Full specification

Product details

Key construction, installation and performance notes for Carat Septic Tank — One / Two Chamber.

Overview

GRAF Carat septic tank with baffle for one-chamber or two-chamber primary settlement. Pair with Anaerobix for anaerobic treatment where required. Source: graf.info septic tanks.

Specification focus

Technical documents
